75 Inch Lcd All-In-One Touch Screen Smart Board Interactive Whiteboard

75 Inch Lcd All-In-One Touch Screen Smart Board Interactive Whiteboard

Product Details:

Place of Origin: CHINA
Brand Name: OEM
Certification: CE/ROSH/FCC
Model Number: HN-7501

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Price: negotiate
Packaging Details: carton( wooden box ,flight case optional)
Delivery Time: 7-10 working days
Supply Ability: 10000pcs/month
Get Best Price Contact Now

Detail Information

Size: 75 Inch(55“65”86“98”110“ Optional ) Whiteboard Type: Interactive Whiteboard
Brightness: 350 Nits Viewing Angle: 178°(H) / 178°(V)
Touch Points: 20 Points Resolution: 3840*2160(4K)
Connectivity: Wi-Fi, Bluetooth, USB, HDMI Microphone: Built-in
Pixel Pitch: 0.4845(H)*0.4845 (V) Other Name: Flat Panel Smart Board
Panel Sensor: Pressure Sensing Responsive Time: 8ms
Technology: Infrared|electronic|digital|IR Touch Panel Glass: 4mm Tempered AG Glass (7H Hardness)
Aspect Radio: 16:9... Android Version: Android 14

Product Description

75 Inch Lcd All-In-One Touch Screen Monitor Interactive Whiteboard




Description:

Humane, intelligent sound control: adjust the volume disposable via remote control under different environmental.
Flexible program arrangements: adjust programs golden section and the non-prime segment arrangements by software.
Safely locking system function to avoid take way flash memory card and advertising playing content, also can be protected by input password.
Stylish appearance, absolute focus of products' promotion for senior client, product appearance, color can be customized according to the actual needs.
Absolute burglar with locks to protect the fuselage,with a security lock to protect the U disk / SD card not been stolen and the contents of the file not been Leak.
Safely locking system function to avoid take way flash memory card and advertising playing content, also can be protected by input password.
Stylish appearance, absolute focus of products' promotion for senior client, product appearance, color can be customized according to the actual needs.
Absolute burglar with locks to protect the fuselage,with a security lock to protect the U disk / SD card not been stolen and the contents of the file not been Leak.
Built-in clock.
Built-in speaker, stereo audio output.
Remote control,easy to operate and high confidentiality.
Easy installation, no need to damage the building wall,installation flexibility.
The operation is simple, just plug in the memory card, turn on the power, and it is working.
Rolling marquee, logo, volume, dynamic anyway playback, change the program without drawing card.
Memory card protection: card intelligent power management to ensure the service life of the card.
Can be connected to a network, transmission and playback the media files through the network(optional).

75 Inch Lcd All-In-One Touch Screen Smart Board Interactive Whiteboard 075 Inch Lcd All-In-One Touch Screen Smart Board Interactive Whiteboard 1

General Specifications:

Panel Specifications
Items Specification Unit
Panel Size  75 (support custom make) Inch
Panel Type TFT-LCD /
Display Colors 10 bit, 16.7 Million Colors
Number of Pixels 1920 x 1080 Pixel
Luminance of White 300 (Typ.) cd/m2
Contrast 3000:1 (Typ.) /
Viewing Angle ±178 (wide) Degree
Aspect Ratio 16:9 /
Response Time 6 (Typ.) m-sec
Life Time 60,000 Hours
Appearance
Color  black and customized
Case 2mm cold-rolled sheet
Paint Process 170°~ 180°Baking finish
Application Wall mount or fix on the stand bracket
Protection 4mm tempered glass
Others
Power Input AC 100 ~ 240V, 50/60 Hz
Max. Power Consumption ≤80KW/h
Standby Power Consumption ≈5W
IP Code IP20
Working Temperature 0 ~ 40°
Storage Temperature -20 ~ 55°
Working Humidity 20% ~ 80%
Storage Humidity 10% ~ 90%
Unit Package PE film + Foam corner protector + Carton
Export Package Export wooden packing
Accessories Driver CD, User Manual, SD card, Electronics Cable
Warranty 1 Year




According to customer’s feedback and market demand, Screenage has released two different solutions to meet client’s standard. Please kindly check below solutions carefully to find the best one for you.



Solution Specifications for STAND-ALONE version

PCB Specifications
Items Specifications
Supported Format Video Format MPG, MPG-1, MPG-4, AVI, MP4, DIV, TS, TRP, WMV, M2TS, MKV, RM, RMVB
Image Format JPEG, BMP, PNG
Audio Format MP3, WMA
Video Decoding Resolution Ratio 1920 x 1080 @60Hz (Max)
Color Depth 24bit (Max)
Frame Rate 30frm/s (Max)
Code Stream USB2.0 device: 30Mbit/sec (Max)
Audio Decoding Sampling Rate 32KHz, 44.1KHZ, 48KHz, 96KHz
Bit Rate 32kbps to 448kbps
Ports USBx1, HDMIx1, SD card plugx1
Frequency Response USB2.0 Max480Mbps
Language English (default) and multi



Solution Specifications for Netversion

Android Specifications
Parts Specifications
Processor All-winner, A20 (1.0G, dual core)
RAM 1G, DDR3
Memory Build-in FLASH memory 8G
Multiple Storage Media Support Support USB 2.0/ SD/ MMC card
Video Output HDMI Video Output
Audio Output Dual-channel stereo audio output
Remote control Available
Operation System Android 4.2.0
OS language English (Default, multi language supported)
I/O USB2.0 x 2, RJ-45 x 1, TF card plug x 1, AV x 1,HDMI x 1,DC x 1
WIFI Include
3G module Optional







Digital signages are used for many different purposes. Below are some of the most common applications of digital signage:

  1. Public information – news, weather, traffic and local (location specific) information, such as building directory with map, fire exits and traveler information.
  2. Internal information - corporate messages, such as health & safety items, news, and so forth.
  3. Menu information – pricing, photos, ingredients, and other information about the food(s) being offered, including nutritional facts.
  4. Advertising – usually either related to the location of the sign or using the audience reach of the screens for general advertising.
  5. Brand building – in-store digital sign to promote the brand and build a brand identity.
  6. Influencing customer behavior – directing customers to different areas, increasing the "dwell time" on the store premises, and a wide range of other uses in service of such influence.
  7. Enhancing customer experience – applications include the reduction of perceived wait time in the waiting areas of restaurants and other retail operations, bank queues, and similar circumstances, as well as demonstrations, such as those of recipes in food stores, among other examples.
  8. Enhancing the environment – with interactive screens (in the floor, for example, as with "informational footsteps" found in some tourist attractions, museums, and the like) or with other means of "dynamic wayfinding".

Features:

  1. Thief-proof
  2. Ultra-thin and ultra-light transmission tempered glass or acrylic protective layer
  3. Fully enclosed aluminum frame, cold-rolled steel design shell
  4. Industrial grade paint technology, smooth and uniform, waterproof and dustproof, anti dust and mill
  5. Design for both horizontal and vertical use
  6. Ultra-high-fidelity sound, pleasant stereo sound
  7. Remote controller adopt password control, access control and softdog U dish
  8. Support picture split, video split, rolling marquee, timing ON/OFF, playlist setting, ect
  9. Long time stable operation, adopt wide viewing angel technology, high brightness industrial LCD panel



FAQ:

Q: What’s the difference between STAND-ALONE version and Netversion?

A:

Items Stand-alone version Netversion
Play Images, videos, audios Yes Yes
Content update By manual work By Internet
Display Schedule By manual work By Internet
Monitoring No Yes
Timing Yes Yes



Q: Can Custom make the size, color and other functions?

A: Be based on our professional engineer team and our own metal work plant, Screenage not only can provide our standard, but also can provide OEM&ODM service.



Q: What’s the MOQ?

A:or our standard product is 1pc, 10pcs for custom make.
