OEM ODM Outdoor LCD Digital Signage With 2000 Nits Touch Screen

OEM ODM Outdoor LCD Digital Signage With 2000 Nits Touch Screen

Product Details:

Place of Origin: Guangdong,China
Brand Name: HONGNUO
Certification: 3C, FCC, CE, ROHS
Model Number: HN-3201OLDS

Payment & Shipping Terms:

Minimum Order Quantity: 1 PC
Price: Negotiable
Packaging Details: Packed in carton with EPE and foam, carton in wooden case.
Delivery Time: 5-10 work days upon payment
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 500 Pieces Per Month
Get Best Price Contact Now

Detail Information

Brand Name: HONGNUO Resolution: 1920*1080
Operating System: Android/Windows Brightness: 2000nits
Operating Temperature: -20℃~50℃ Warranty: 12 Months
Highlight:

ODM Outdoor LCD Digital Signage

,

OEM Outdoor LCD Digital Signage

,

2000Nits touch screen digital signage

Product Description

HONGNUO Waterproof 32 43 49 inch 2000nits touch screen kiosk o

utdoor advertising digital display screens



Main features

  1. The whole machine adopts modular design, standardized design, the working state is clear at a glance, which can realize fast maintenance;
  2. Temperature control system can adjust the internal temperature and humidity of the equipment, to ensure that the equipment operates in an environment of -25 ~ 50 degrees;
  3. Super long life, 7*24 hours uninterrupted work, up to 60,000 hours or more;
  4. Superior energy-saving air-cooLCD cooling system with stable and reliable performance;
  5. The galvanized steel with outdoor powder painting can ensure the enclosure is anti rust for more than 10 years. Also it has patent electricity leaking protection design and lighting and thunder protection design, all these can make sure the outdoor touch screen information can work properly outside in rainy day andy sunny day.

​Destription

All-weather display of business information even when the sign is exposed to direct or indirect sunlight, or to harsh environmental conditions such as dust, water and heat. It is mechanically designed to withstand high temperatures and can withstand a wide operating range: -30°C (-22°F) to 50°C (122°F) with an intelligent temperature regulation system
The display's waterproof and dustproof design covers fans, drainage holes, plugs and power outlets, and features IP56 certified protection to meet international protection standards against breakage, scratches and smudges to optimize signage for outdoor use.



specification

Component

Specification

Parameter

Remark

Structure

grass

Using 6mm high permeability toughened glass

optional

Display size

 32/43/49 inch



Display ratio

16:9



Resolution

1920*1080



Display screen

Brightness

2000nits

optional

Viewing angle

178° horizontal / 178° vertical



Brightness control

automatic



Backlight

LCD backlight



Touch

10-point touch

Null

optional

Default configuration motherboard

A20 dual-core Android solution

optional

Mother- board

WIFI

Null

optional

Playback software

Support network program release,local program update, stand-alone mode playback



Switching power supply

Industrial grade power supply



Waterproof speaker

Waterproof high-quality 10W speaker



Electric control

Lightning protection device

Three-level lightning protection



leakage protector

Anti-leakage



Timer

Customized switch machine can be set
according to day, week and month



Heat dissipation

Intelligent direct ventilation
heat dissipation and heating system

Intelligent cooling system, unique design of air duct and main board, automatic adjustment of wind speed and air volume



Intelligent temperature sensing system, high temperature automatically turns off the display



Low temperature self-starting heating module



Working parameters

Operating temperature

-30℃~50℃



Operating humidity

5%~95%



Operating Voltage

AC 110V~220V/50Hz



Maximum power consumption

380 W




OEM ODM Outdoor LCD Digital Signage With 2000 Nits Touch Screen 0

Application

Public Places: subway, airports, stations, gas stations, toll stations, bookstores, parks, exhibition halls, stadiums, museums, convention centers, ticket agencies, HR market, lottery centers;
Business Organizations: supermarket, large-scale shopping malls, exclusive agency, chain shops, large-scale sales, star-rated hotels, restaurants, travel agencies, pharmacy.
Financial Organizations: Banks, negotiable securities, funds, insurance companies, pawnshops;
Non-profit Organizations: Telecommunications, post offices, hospital, schools;
Real Estate Property: Apartments, villas, offices, commercial buildings, model rooms, property brokers;
Entertainments: Movie theaters, fitness halls, country clubs, clubs, massage rooms, bars, cafes, Internet bars, beauty shops

OEM ODM Outdoor LCD Digital Signage With 2000 Nits Touch Screen 1



Company Profile

HongNuo Company was founded in 2009, focusing on OEM/ODM of advertising machines for 13 years, We have qualitative products as well as professional sales and technical team, so we are able to provide customers with good products, excellent technical support and perfect after-sales service.

We deliver quality services at equitable rates and focus on constant improvement in all areas of our operation, with a strong commitment to meeting our customer's needs. We view you and yours more as a business partner than merely a buyer. At HONGNUO "customer is always first" and partnering is our path to customer satisfaction.

OEM ODM Outdoor LCD Digital Signage With 2000 Nits Touch Screen 2



Custom Designs

HONGNUO is an OEM / ODM factory, customizing your products to tailor your needs is our strength. Our team of designers , software engineers and structure engineers will make sure to render your imagination into actual products!

factory production + software development + ID design + structural design, etc. These teams belong to our own.



Please contact our customer service for more details.
